GEMINI 1500 - CAST IRON DOOR N.E.
DB05155--
The reference plan contains the numbers used in the table below to identify parts.
| # | Part (sold individually) | Price | Availability | |
|---|---|---|---|---|
| 1 | AC07860 1/2" BRASS COIL HANDLE 1 / appliance (sold individually) | CAD $8.00 | -- | |
| 2 | AC09185 DOOR LATCH KIT 1 / appliance (sold individually) | CAD $30.00 | -- | |
| 2 | AC09155 HANDLE & LATCH KIT 1 / appliance (sold individually) | CAD $55.00 | -- | |
| 3 | 99998 DISCONTINUED 1 / appliance (sold individually) | -- | -- | |
| 4 | SE04636-05 20 5/16" x 7 3/4" x 8 7/8" ARCHED GLASS WITH GASKET 1 / appliance (sold individually) | CAD $200.00 | -- | |
| 5 | AC06100 SILICONE AND 1/4" x 1/2" x 8' BLACK DOOR GASKET KIT 1 / appliance (sold individually) | CAD $15.00 | -- | |
| 6 | PL08535-06 GLASS RETAINER KIT 3 / appliance (sold individually) | CAD $15.00 | -- | |
| 7 | PL04910-01 ASHPAN DECORATIVE MOULDING GEM 1500 GOLD 1 / appliance (sold individually) | CAD $46.00 | -- | |
| 8 | AC07861 1/4" BRASS COIL HANDLE 1 / appliance (sold individually) | CAD $7.00 | -- | |
| 9 | PL03807 GEM 1500.CASSANDRA FIRESTOP 1 / appliance (sold individually) | CAD $70.00 | -- | |
| 10 | PL04947-02 GEMINI 1500 BACK MOULDING GOLD 1 / appliance (sold individually) | CAD $21.00 | -- | |
| 11 | 29010 4 1/2" x 9" x 1 1/4" REFRACTORY BRICK 17 / appliance (sold individually) | CAD $10.00 | -- |
The number appears on the reference plan provided above the table.
Note that the quantities per unit listed above are the standard quantities found in each appliance, not the number of items you need to order.
