The reference plan contains the numbers used in the table below to identify parts.
| # | Part (sold individually) | Price | Availability | |
|---|---|---|---|---|
| 1 | SE70731 WOOD HANDLE KIT 1 / appliance (sold individually) | USD $42.00 | -- | |
| 2 | AC09185 DOOR LATCH KIT 1 / appliance (sold individually) | USD $30.00 | -- | |
| 3 | SE70730 TEMPLATE SE 1 / appliance (sold individually) | USD $85.00 | -- | |
| 4 | 30101 SPRING TENSION PIN 5/32"Ø x 1 1/2"L 1 / appliance (sold individually) | USD $2.00 | -- | |
| 5 | SE24343 DECO II DOOR ASSEMBLY 1 / appliance (sold individually) | USD $210.00 | -- | |
| 6 | AC06500 SILICONE & 5/8" x 8' BLACK DOOR GASKET KIT 1 / appliance (sold individually) | USD $17.00 | -- | |
| 7 | SE70890 16 3/4''W x 10 7/8''H DROLET DECO II GLASS 1 / appliance (sold individually) | USD $150.00 | -- | |
| 8 | AC06400 3/4" x 6' FLAT BLACK SELF-ADHESIVE GLASS GASKET 1 / appliance (sold individually) | USD $10.00 | -- | |
| 9 | SE70729 GLASS AND MOULDING KIT 1 / appliance (sold individually) | USD $270.00 | -- | |
| 10 | PL70889 RIGHT GLASS FRAME 2 / appliance (sold individually) | USD $24.00 | -- | |
| 11 | SE53585 GLASS RETAINER KIT WITH SCREWS (12 UNITS) 1 / appliance (sold individually) | USD $20.00 | -- | |
| 12 | 30154 BLACK ZINC SCREW #10 x 5/8" QUADREX #2 TYPE A 10 / appliance (sold individually) | USD $12.00 | -- | |
| 13 | PL70966 AIR CONTROL HOUSING PLATE 1 / appliance (sold individually) | USD $26.00 | -- | |
| 14 | PL70902 ASH SHELF 1 / appliance (sold individually) | USD $34.00 | -- | |
| 15 | 30507 BLACK TORX SCREW WITH FLAT HEAD TYPE F 1/4-20 x 3/4" 4 / appliance (sold individually) | USD $2.00 | -- | |
| 16 | 30187 STAINLESS WASHER IØ 17/64" x 1/2" OØ 1 / appliance (sold individually) | USD $1.00 | -- | |
| 17 | 30206 ZINC WASHER 5/16"IØ x 3/4"OØ 1 / appliance (sold individually) | USD $1.00 | -- | |
| 18 | 30094 HEX SCREW WASHER HEAD 1/4-20 x 3/4" F ZINC TYPE 1 / appliance (sold individually) | USD $2.00 | -- | |
| 19 | 30782 HEX FLANGE NUT SERRATED 1/4-20 STAINLESS 18-8 1 / appliance (sold individually) | USD $1.00 | -- | |
| 21 | AC01299 RIGID FIRESCREEN 1 / appliance (sold individually) | USD $140.00 | -- | |
| 22 | 30898 BLACK ROUND WOODEN HANDLE 2 / appliance (sold individually) | USD $15.00 | -- | |
| 23 | SE70906 ASH DRAWER ASSEMBLY 1 / appliance (sold individually) | USD $95.00 | -- | |
| 24 | SE70893 AIR INTAKE BOX ASSEMBLY 1 / appliance (sold individually) | USD $150.00 | -- | |
| 25 | AC01336 5"Ø FRESH AIR INTAKE KIT 1 / appliance (sold individually) | USD $90.00 | -- | |
| 26 | SE74167 DOOR HINGE REPLACEMENT KIT 1 / appliance (sold individually) | USD $43.00 | -- | |
| 27 | SE70737 REAR HEAT SHIELD ASSEMBLY 1 / appliance (sold individually) | USD $280.00 | -- | |
| 28 | PL70704 BLOWER ADAPTER 1 / appliance (sold individually) | USD $50.00 | -- | |
| 29 | PL70713 AIR DEFLECTOR 1 / appliance (sold individually) | USD $25.00 | -- | |
| 30 | 29015 4" x 9" x 1 1/4" REFRACTORY BRICK 12 / appliance (sold individually) | USD $10.00 | -- | |
| 31 | 29010 4 1/2" x 9" x 1 1/4" REFRACTORY BRICK 4 / appliance (sold individually) | USD $3.50 | -- | |
| 32 | PL36274 3 5/8" x 5 3/4" x 1 1/4" REFRACTORY BRICK 1 / appliance (sold individually) | USD $10.00 | -- | |
| 33 | 24096 ROUND CAST IRON ASH PLUG 1 / appliance (sold individually) | USD $25.00 | -- | |
| 34 | 21586 18 7/8" x 9 1/2" x 1 1/4" VERMICULITE BAFFLE 1 / appliance (sold individually) | USD $65.00 | -- | |
| 35 | PL70516 SECONDARY AIR TUBE 4 / appliance (sold individually) | USD $50.00 | -- | |
| 36 | AC02055 QUICK CONNECT THERMODISC 1 / appliance (sold individually) | USD $49.00 | -- | |
| 37 | 44028 CERAMIC THERMODISC F110-20F 1 / appliance (sold individually) | USD $25.00 | -- | |
| 38 | 44073 CROSSFLOW BLOWER 115V-60Hz-39W 100 CFM 1 / appliance (sold individually) | USD $200.00 | -- | |
| 39 | AC02050 BLOWER WITH VARIABLE SPEED CONTROL | 100 CFM 1 / appliance (sold individually) | USD $150.00 | -- | |
| 40 | 60013 POWER CORD 96" x 18-3 1 / appliance (sold individually) | USD $20.00 | -- | |
| 41 | 44085 RHEOSTAT KNOB 1 / appliance (sold individually) | USD $8.00 | -- | |
| 42 | 44087 RHEOSTAT NUT 1 / appliance (sold individually) | USD $5.00 | -- | |
| 43 | 44080 RHEOSTAT WITHOUT NUT (AC-11) 1 / appliance (sold individually) | USD $55.00 | -- | |
| 44 | 99998 DISCONTINUED 1 / appliance (sold individually) | USD $14.00 | -- | |
| 45 | AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL 1 / appliance (sold individually) | USD $17.00 | -- | |
| 46 | PL75747 1.7 SERIES SECONDARY AIR TUBE 1 / appliance (sold individually) | USD $49.00 | -- |
The number appears on the reference plan provided above the table.
Note that the quantities per unit listed above are the standard quantities found in each appliance, not the number of items you need to order.
