CAPE TOWN 1800 - CAST IRON

DB04900

Review this product

USD $4,399.00

Heating area500 - 2,000 ft²

RECOMMENDED AREA MAP BY CLIMATE ZONE

Size30 3/4" W X 22 5/8" D X 32 5/8" H

Maximum log length21"

Average particulate emission rate1.91 g/h

Description

Entirely made of cast iron, the Cape Town 1800 is ideal for heating up to 2000 ft² with its 75,000 BTU/h of maximum power. Certified at 1.81 g/h, this non-catalytic unit is the only Drolet model to offer a flue outlet at the back and on the top of the stove. The Cape Town 1800 has a large viewing area as well as a full width andiron to hold logs during loading. Its classic design and distinguished cast iron finish give it all its charm.

Included: ash drawer, ceramic glass, ash lip, broad-spectrum air damper

▪ Up to 8 hours burn time
▪ Up to 21" logs
▪ 2 ft³ firebox
▪ EPA certified
▪ Made in Belgium
▪ Limited lifetime warranty
▪ Certified for mobile home and alcove installation
▪ This model qualifies for the US tax credit

Any installation must be done according to the data and drawings detailed in the owner’s manual.

Options

Specifications

Fuel type	Dry cordwood (16" recommended)
Heating area (9)	500 - 2,000 ft²
Overall firebox volume	2.0 ft³
EPA loading volume	1.55 ft³
Maximum burn time (9)	8 h
Maximum heat output-dry cordwood (4)	51,600 BTU/h (15.13 kW)
Minimum overall heat output rate (4) (5)	13,927 BTU/h (4.08 kW)
Maximum overall heat output rate (4) (5)	51,616 BTU/h (15.13 kW)
Average overall efficiency-dry cordwood (HHV) (5) (6)	76 %
Average overall efficiency-dry cordwood (LHV) (5) (7)	82 %
Optimum efficiency (1) (2)	84.5 %
Optimum heat transfer efficiency (8)	77 %
Average particulate emission rate (3)	1.91 g/h
Average CO (10)	79 g/h
Size	Large
Alcove installation approved	Yes
Certified according to applicable standards	By an accredited laboratory (CAN/USA)
Overall dimension (Width)	30 3/4"
Overall dimension (Height)	32 5/8"
Overall dimension (Depth)	22 5/8"
Premium quality blower included (CFM)	No
Combustion technology	Non-catalytic
Flue outlet diameter	6"
Distance-center of the flue outlet to back unit	4 1/8"
Distance-center of the flue outlet to side unit	15 3/8"

Distance-center of the flue outlet to floor	26 3/4"
Recommended chimney diameter	6"
Type of chimney	CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height	12'
Door type	Single, glass with cast iron frame
Door opening size (Width)	22"
Door opening size (Height)	9 1/2"
Glass type	Ceramic glass
Glass surface - W x H	20 1/2" x 12"
Firebox size (Width)	21 7/8"
Firebox size (Height)	9 1/2"
Firebox size (Depth)	13 1/4"
Log positioning	Loading over width
Maximum log length	21"
Firebox lined with refractory bricks	No
Baffle type	High quality vermiculite
High-efficiency certified appliance	Yes, EPA 2020 approved
Canadian Standard (emissions)	CSA B415.1-10
USA Standard (emissions)	EPA
Canadian Standard (safety)	ULC S627
USA Standard (safety)	UL 1482
Warranty	Limited lifetime
Shipping weight	545 lb (247 kg)
Moulded refractory panels	Yes

Clearances to combustibles*	Canada United-States
	Single wall pipeDouble wall pipeSingle wall pipeDouble wall pipe
Clearance - Back wall	18"10"18"10"
Clearance - Corner	16"8"16"8"
Clearance - Side wall	16"16"16"16"
Clearance - Base of the unit to ceiling**	84"84"84"84"

*The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

**Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.

1. Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.
2. Optimum overall efficiency at a specific burn rate (LHV).
3. This appliance is officially tested and certified by an independent agency.
4. The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³. Other performances are based on a fuel load prescribed by the standard. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.
5. As measured per CSA B415.1-10 stack loss method.
6. Higher Heating Value of the fuel.
7. Lower Heating Value of the fuel.
8. The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the solid fuels into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.
9. Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.
10. Carbon monoxyde.
